Crown DCi 8 300 DriveCore Install 8-Channel 300 Watt Amplifier

Crown DCi 8 300 DriveCore Install 8-Channel 300 Watt Amplifier

Crown DCi 8 300 DriveCore Install 8-Channel 300 Watt Amplifier

The DriveCore„¢ Install series amplifiers is a complete line of high performance installation amplifiers based on the proprietary DriveCore technology. DCi Series amplifiers are designed, engineered and manufactured to the industry€™s highest quality standards, and provide system integrators with the advanced features and flexibility required for challenging 21st century installed sound applications. Versatile, compact and highly energy-efficient, DCi Series amplifiers continue the unbroken Crown tradition of leadership in professional and commercial power amplifier technology.

Features:

  • True rack density €“ Offers power points of 300W or 600W in 2-, 4-, or 8-channel configurations within a 2 Rack Unit form factor. More channels in one unit allow for smaller infrastructure rooms, reducing operational costs and maximizing installation flexibility.
  • Direct drive constant voltage €“ Saves money by using smaller gauge wiring to drive speakers at 70V RMS or 100V RMS, eliminating the need for a step-up transformer at the output for improved audio quality and efficiency.
  • Channel independent hi-Z/low-Z selection €“ Drives one or two speakers in low-Z mode or hundreds in high-Z mode (70V RMS or 100V RMS), offering design flexibility with channel-by-channel load management.
  • Bridgeable channel pairs €“ The DCi series channels are bridgeable, even in 100V RMS mode, for greater adaptability in high-power applications such as subwoofers.
  • Remote on/off interface €“ Integrates the amplifier into a control system for easy power management, allowing the system to be turned on and off remotely to save energy.
  • Efficient cooling design €“ Internal cooling fans provide targeted airflow to heat-generating components, maximizing cooling efficiency while minimizing energy waste and noise.
  • Advanced power factor correction (PFC) universal power supply €“ A high-efficiency power supply operates in varied conditions, reducing power dissipation and heat within rack setups.

Specifications:

  • Output channels: 8
  • Frequency response (8Ω, 20Hz - 20kHz): ±0.25dB
  • Total harmonic distortion (at full rated power, 20Hz - 20kHz): 0.35%
  • Damping factor (20Hz to 100Hz): >1000
  • Load impedance (stereo/dual mode): 2Ω - 16Ω; 70Vrms and 100Vrms
  • Load impedance bridge mono: 4Ω - 16Ω; 140Vrms and 200Vrms
  • Cooling: Continuously variable speed forced air, front to back airflow
  • Maximum fan noise (re dBA SPL @ 1M): 47
  • Required AC mains (±10%): 100V-240V ~ 50/60Hz
  • Power connector: 15A IEC
  • Dimensions:
    • W x H x D: 483 mm x 89 mm x 362 mm
    • 19 in x 3.5 in x 14.25 in
  • Weight: 10.66 kg (23.5 lbs)
