EAW 2070747-70 NTX210L 2-Way Self-Powered Loudspeaker - Black

EAW 2070747-70 NTX210L 2-Way Self-Powered Loudspeaker - Black

EAW 2070747-70 NTX210L 2-Way Self-Powered Loudspeaker - Black

Building on the Radius line of loudspeakers, NTX Series aims to deliver a high performance solution while cutting down long set up times. NTX Series couples unique and intelligent features with EAW€™s signature acoustical design to deliver solutions for rental firms, production companies, and system integrators. The NTX articulated array features OptiLogic, providing automatic array self- detection and instant optimization including air loss compensation and more. Resolution 2„¢ software provides system optimization from anywhere in the venue, plus intuitive room design and prediction in a single, comprehensive application. With the proven sonic performance of EAW€™s acoustic design and DSP mastery plus full Dante integration across the line, NTX Series delivers an intelligent and flexible system to fit any budget.

Features:

  • Array self-detection via onboard infrared sensors and accelerometers for near-instant optimization that cuts down on setup and tuning time.
  • Comprehensive software that delivers system prediction, control, and monitoring from any location in the venue.
  • Integrated Dante„¢ networking (with loop-thru) including Analog redundancy capability.

Specifications:

  • Performance:
    • Calculated Axial Output Limit (whole space SPL):
      • Peak 140dB LF/HF (12dB Crest Factor)
    • Operating Range: 55Hz€“18kHz
    • Nominal Beamwidth:
      • Horz: 90°
      • Vert: 12°
    • Configuration:
      • Subsystem Transducer Loading:
        • LF 2x10" cone, 2.5" VC Vented
        • HF 1x1.4" exit, 3" VC compression drivers Isophasic Wave Guide
      • Operating Mode:
        • Bi-amp LF, HF
      • Amplifier Channels External Signal Processing:
        • DSP w/EAW Focusing„¢ & DynO„¢
    • Electrical:
      • Input Type: Electronically Balanced
      • Max Input Level: 21dBu
      • Impedance: 20 kOhm (balanced)
      • Input Wiring: XLRF, Pin 1 chassis, pin 2 +, pin 3 €“ separate loop-thru XLRM (for analog signal only)
      • Input Selection: Analog, Dante
      • Amplifiers & Processing (LF/HF) Type: Modified Class D
      • Maximum Output:
        • LF: 1200W
        • HF: 400W
      • Driver Protection: Integral DSP limiting
      • AC Mains (nominal):
        • Connector: Neutrik True1
        • Input: 100 V TO 240 V
        • Frequency: 50 Hz to 60 Hz
      • Power Consumption:
        • Idle €“ 20W
        • 1/8th - 200W
        • 1/3rd - 300W
        • Full - 550W
      • Controls/Communication:
        • Connections: Neutrik PowerCON TRUE1 TOP
        • Protocols: Ethernet/Dante
        • Software: EAW Resolution 2„¢
