RCF TT515-A Active Dual 5 Inch Powered Speaker - RDNET Ready

RCF TT515-A Active Dual 5 Inch Powered Speaker - RDNET Ready

RCF TT515-A Active Dual 5 Inch Powered Speaker - RDNET Ready

The TT 515-A is designed for both installed and portable professional applications, offering flexibility, power, and compactness where size and weight are critical. It leverages the benefits of TT+ technology, including controlled dispersion, exceptional clarity, and extreme power. The system features various flexible rigging accessories, weatherproof protection, and RDNET real-time monitoring and management software with recallable presets. Its transducer configuration includes two custom-loaded 5-inch cone drivers paired with a rotatable CMD waveguide and a titanium 1.75-inch high-frequency compression driver. Whether utilized as a compact main system, fills, or surrounds in a larger setup, the TT 515-A is designed for quick deployment and rapid tuning.

Features:

  • 127 dB max SPL
  • 100° x 70° coverage
  • LF 2 x 5" neodymium woofer, 2€� voice coil
  • HF 1.75€� titanium comp. driver
  • 2 x Class-D amplifiers, 1000 Watts RMS total power
  • 70 €“ 20,000 Hz frequency range
  • RDNet on board
  • FiRPHASE and Bass Motion Control

Specifications:

  • Frequency Response: 70Hz - 20,000Hz
  • Max. SPL (@ 1m): 127 dB
  • Coverage Angle (HxV): 100° x 70°
  • Transducers
    • Compression Driver: 1x1.0'' neo, 1.75'' v.c
    • Woofer: 2x5.0'' neo, 2.0'' v.c
  • Input/Output Section
    • Input Signal: bal/unbal
    • Input Connectors: XLR, RDNet Ethercon
    • Output Connectors: XLR, RDNet Ethercon
    • Input Sensitivity: -2dBu/+4dBu
  • Processor Section
    • Crossover Frequencies: 1200
    • Protections: Excurs.
    • Limiter: Fast Limiter
    • Controls: Bypass, Linear/High Pass, Volume, RDnet on board
    • RDNet: yes
  • Power Section
    • Total Power: 2000W Peak, 1000W RMS
    • High Frequencies: 600W peak, 300W RMS
    • Low Frequencies: 1400W Peak, 700W RMS
    • Cooling: convection
    • Connections: Powercon IN/OUT
  • Physical Specifications
    • Cabinet/Case Material: Baltic birch plywood
    • Hardware: 2X M10 TOP AND BOTTOM 2X PIN D.10
    • Handles: 2 top and bottom
    • Grille: steel
  • Dimensions (HxWxD): 17.95x6.06x9.35"
  • Weight: 21.61 pounds
